Integrated Ethernet MAC, Physical chip and transceiver one chip
Compliant to PCI Revision 2.1/2.2
PCI local bus single-chip Fast Ethernet controller
Supports PCI target fast back-to-back transaction
Supports PCI clock 16.75MHz-40MHz
Supports a 32-bit general-purpose timer, referenced by the external PCI clock source, and timer-interrupt
Include a programmable, PCI burst size and early tr/rx threshold
Supports digital and analogue loop back capability on both ports
Supports ACPI, PCI power management
Supports LAN WAKE-UP function
Complies with the IEEE 802.3 CSMA/CD, 100Base-TX and 10Base-T standard
Supports Full Duplex Flow Control (IEEE 802.3x)
Full duplex design to double the performance to 20Mbps/200Mbps
Supports Auto-Negotiation function
Auto-detects network speed
Auto-setups IRQ and I/O address
Contains two large (2Kbyte) independent receive and transmit FIFOs
One STP/UTP connector for 10Mbps or 100Mbps network speed
Provides diagnostic software and two LEDs to indicate network Link/Activity
Supports smart remote boot ROM and provides the help for Windows NT4.0 remote boot Windows 95( NF-3283/NF-3239)
Supports ODI Driver for NetWare 3.x, 4.x, NDIS Driver for LAN Manager, Microsoft Windows 95, Windows NT, Windows 2000,UNIX,Packetdriver for TCP/IP
