Exceptional wireless speed up to 150Mbps
Wireless security encryption easily at a push of QSS button
Supports SPI firewall and access control management for safer usage
QoS enables multiple applications to stream smoothly to Your TV or PC
Compact design enabling flexible deployment
|
Software Specification |
Standards |
IEEE 802.11n*, IEEE 802.11g, IEEE 802.11b |
Wireless Signal Rates |
Up to 150Mbps |
Frequency Range |
2.4-2.4835GHz |
Wireless Transmit Power |
20dBm(max. EIRP)** |
Modulation Technology |
DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM |
Receiver Sensitivity |
130M: -68dBm@10% PER 54M: -68dBm@10% PER 11M: -85dBm@8% PER 6M: -88dBm@10% PER 1M: -90dBm@8% PER |
Hardware Specification |
Interface |
4 10/100M LAN Ports
1 10/100M WAN Port |
Antenna |
3dBi Fixed Omni Directional Antenna |
Power Supply Unit |
Input: Localized to Country of Sale
Ouput: 9VDC/0.85A Switching PSU |
Operating temperature |
|
Storage temperature |
-40°C~70°C |
Relative humidity |
10% ~ 90%, Non-Condensing |
Storage Humidity |
5%~95% Non-Condensing |
Dimensions |
5.9 x 3.9 x 1.1 in. (150 x 100 x 28 mm) |
|
