Interface Port RJ-45 connectorPCI
specification 2.2 compliant
Data Connection Data transfer rate: 10/100/1000Mbps
32K transmit FIFO and receive FIFO
Standard Compliance IEEE 802.3 10BaseT
IEEE802.3u 100BaseTX
IEEE802.3ab 1000BaseT
IEEE 802.3x Full Duplex Flow Control
IEEE 802.1q VLAN tagging
Power Managerment Wake-on-LAN (WoL)
LED ACT: ON-NIC card is functioning
10: Flashing-NIC card is transferring data at 10Mbps
100: Flashing-NIC card is transferring data at 100Mbps
1000: Flashing-NIC card is transferring data at 1000Mbps
Dimension 119 (L) x 43 (W) x 16(H) mm
Unit Weight 50g
Power Consumption 1.5W
Environmental Specification Operating temperature: 0°C ~55°C
Operating humidity: 5% ~95% (non-condensing)
Storage temperature: -25°C ~75°C
Emission CE, FCC, VCCI, C-Tick MIC
Support OS Window 98/98SE, ME, 2000 and XP
