Network Standard IEEE802.11b, IEEE802.11g, IEEE802.11n
Interface USB2.0
Antenna 2 * Internal Antenna (3D enhanced MIFA antenna on USB connector ).
Operating Frequency 2.4 ~ 2.5 GHz
Operation Channel 11 for N. America, 13 Europe (ETSI), 14 Japan
Data Rate 802.11n:Tx: 150Mbps (Max) / Rx: 150Mbps (Max)
802.11g:54/48/36/24/18/12/9/6Mbps
802.11b:11/5.5/2/1Mbps

Output Power 11b 17 +/- 1 dBm
11g 15 +/- 1 dBm@54Mbps
11n 13 +/- 1 dBm (14.5dBm)

LED Indicator OFF: All others states
ON: Radio On and Associated, WPS Associating
Blink: Radio On and Scanning
Flash: Radio On and Associated and TX/RX Data
Modulation OFDM: BPSK, QPSK, 16-QAM, 64-QAM, DBPSK, DQPSK, CCK
Range Up to 150m
Management Xlink Kai( Win XP only)

Utilities Wireless setting:
Diagnose and configure your wireless network settings with on-line trouble shooting feature.
WPS Wizard:
High-speed wireless network is just a few clicks away

Receiver Sensitivity -84 dBm @11 Mbps
-70 dBm @54 Mbps
-67 dBm @64-QAM, 20MHz channel spacing
-64 dBm @64-QAM, 40MHz channel spacing
Certifications CE, FCC, IDA, IC, C-Tick, NCC, GOST
Physical Specifications Dimensions:30mm*17mm*8.5mm
Environmental Specification Temperature: 0 ~ 40° C ambient
Storage Temperature: -10 ~ 70 ° C ambient
Humidity: 5 ~ 90% and must be non-condensing
Package Contents USB Wireless Adapter *1
Quick start guide*1
Support CD *1
Warranty Card*1

Network Architecture Types Infrastructure and ad-hoc
Encryption 64/128-bit WEP, TKIP, AES, WPA-PSK, WPA2-PSK
OS Support Windows 2000/ XP(x86/x64)/ Vista(x86/x64)/ 7(x86/x64)
Mac 10.4/10.5/10.6
Linux: Redhat 9.0 ( Kernel 2.4.20), Ubuntu 9.04 (Kernel 2.6.28-11), Fedora10 (Kernel 2.6.28-11), Ubuntu 8.04( kernel : 2.6.24-24)
