•Supports composite video S-video and RGB (optional) outputs •Power from PS/2 or USB port •On-screen display (OSD) operation status zoom size •Independent horizontal size and vertical size adjustment programmable 2D scaling •No software driver required; compatible with any operating system •Switchable NTSC NTSC-EIAJ (for Japan) PAL PAL-M PAL-N PAL-combination-N and SECAM (via RGB OUT) video system •RGB (optional cable required) output supports the interlace format •Supports position control; zoom and menu buttons •Menu button supports horizontal size vertical size brightness contrast hue saturation sharpness and OSD background color adjustment •Simultaneous display on VGA monitor and TV •Compact form factor: 95 mm (L) x 55 mm (W) x 30 mm (H) •24-bit true-color digitizer
•Video standards: NTSC/NTSC-EIAJ/PAL/PAL-M/PAL-N/SECAM (via RGB out) •Resolutions supported: 640 x 480 (up to 85 Hz) 800 x 600 (up to 85 Hz) and 1024 x 768 (up to 75 Hz) •Input port: DB15 (VGA) •Output ports: Composite video (RCA) S-video and HD15 (VGA) •Front panel controls: Zoom Menu and onscreen display directional controls •Image controls: horizontal and vertical size brightness contrast hue saturation sharpness and onscreen display background
