ADSL Features Full-rate ANSI T1.413 Issue 2
ITU-T G.992.1 (G.dmt)
ITU-T G.994.1 (G.hs)
ITU-T G.992.3 (G.lite.bis)
ITU-T G.992.5
Max 6 kilometers
Data Rates Downstream: Up to 24Mbps
Upstream: Up to 1.5Mbps
ATM Features UNI 3.1 ATM Adaptation Layer Type 5-AAL5
Multiprotocol encapsulation over ATM (RFC 1483)
UBR CBR VBR-rt VBR-nrt
Supports 8PVCs
PPP Features PPP over ATM (RFC 2364)
PPP over Ethernet (RFC 2516)
Switching Features IGMP multicast
IEEE 802.1d transparent learning bridging
Routing Features Classical IP and ARP over ATM (RFC 1577/2225) MER
Static Routing IP TCP UDP ARP
NAT NAPT DNS DDNS DHCP Server
UPnP Virtual Server DMZ Port Trigger
Wireless Features Complies with IEEE802.11n 1 IEEE 802.11g IEEE802.11b
11n: Up to 150Mbps(dynamic)
Security: WEP 64bit/128bit WPA-PSK/WPA2-PSK WPA/WPA2
Provides 64/128bit WEP encryption security and wireless LAN ACL (Access Control List)
Max wireless transmit power: 17dbm
Antenna gain: 3dbi
Frequency Range:2.4~2.4835GHz
Security NAT and SPI Firewall
