Features
150Mbps wireless transmission rate
Provides two methods of operation: Infrastructure and Ad-Hoc
Quick Secure Setup, complies with WPS for worry free wireless security
Supports 64/128-bit WEP, complies with 128 bit WPA standard(TKIP/AES), supports MIC, IV Expansion, Shared Key Authentication, IEEE 802.1X
4dBi omni-directional antenna detachable
Supports Windows 2000/XP/Vista/7
Seamlessly compatible with 802.11b/g/n devices

Specification


Software Specification
Standards IEEE 802.11n,IEEE 802.11g, IEEE 802.11b
Wireless Speed 11n: Up to 150Mbps 11g: Up to 54Mbps 11b: Up to 11Mbps
Frequency Range 2.4-2.4835GHz
Wireless Transmit Power 20dBm(MAX. EIRP)
Modulation Type OFDM/CCK/16-QAM/64-QAM
Receiver Sensitivity (without antenna) 130M: -68dBm@10% PER 108M: -68dBm@10% PER 54M: -68dBm@10% PER 11M: -85dBm@8% PER 6M: -88dBm@10% PER 1M: -90dBm@8% PER
Work Mode Ad-Hoc Infrastructure
Wireless Security 64/128 bits WEP WPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES)
Support Operating System Windows 7(32/64bits), Windows Vista(32/64bits), Windows XP(32/64bits), Windows 2000
Hardware Specification
Interface USB2.0 Hi-Speed connector
Antenna Type 4dBi Detachable Omni-directional Antenna
Certifications CE, FCC
Operating Temperature 0oC~40oC (32oF~104oF)
Storage Temperature -40oC~70oC (-40oF~158oF)
Relative Humidity 10% ~ 90%, non-condensing
Storage Humidity 5%~90% non-condensing
Dimensions 3.7 x 1.0 x 0.4in. (93.5 x 26 x 11mm)
