Do More, Faster
Enjoy fast wireless connectivity for your home or office. The Dual-Band Wireless-N ADSL2+ Modem Gigabit Router has a built-in high-speed ADSL2+ Modem for a fast, "Always On" connection to the Internet. Wireless connections are radio band selectable to avoid interference in your area, and the four built-in Gigabit ports supply high-speed connections to your wired devices.
•The Power of N - Connect everybody in your home at once without wires. Dual Wireless-N radio bands let you choose the one with the least interference in your area. Either one delivers high performance for smooth streaming video, high frame-rate gaming, fast data transfers, and heavy Internet use from multiple users-- all with great range and reduced dead spots. It also connects to your existing Wireless-G, -B, or -A devices.
•Reliable Coverage - Experience coverage you can count on, all around your home. Wireless-N’s Multiple in, Multiple Out MIMO technology actually uses the signal reflections that confuse ordinary wireless technologies to boost range and reduce dead spots.
•Connect Faster - Access more over your network. Connect Gigabit-enabled networked storage drives, computers, printers, and other devices to the four 10/100/1000 Gigabit Ethernet ports and break the bottlenecks other routers suffer.
•Advanced Security - Advanced wireless security and SPI firewall protection designed to help safeguard your home network and computers from most Internet attacks.
Key Features
•Complies with IEEE draft 802.11n version 2.0 standards
•Selectable radio band: 2.4 or 5GHz
•Blazing fast wireless speeds for high bandwidth applications such as video streaming or file sharing
•Performance Investment Protection: Compatibility with Wireless-A (802.11a), Wireless-B (802.11b) and Wireless-G (802.11g) Standards
•All ports support Gigabit speed and Auto-Crossover (MDI/MDI-X) -- no need for crossover cables. Port 1 can be configured as WAN port.
•Wireless Access Lists to enhance wireless security, support WPA and WPA2 and Wi-Fi Protected Setup
•Built-in Storage Link, transform any USB storage device into a NAS
•Built-in Media Server, streams music, video, and photos to any UPnP compatible media adapter
•MIMO technology uses multiple radios to create a robust signal that travels farther and faster, with reduced dead spots.
•Supports Trend Micro feature
•Supports Yahoo search toolbar
Technical Specifications


•Model: WAG320N
•Standards: Draft 802.11N, 802.11g, 802.11b, 802.3u, G.992.1 (g.dmt), G.992.2 (g.lite), G.992.3/4 (ADSL2), G.992.3 Annex L (ADSL2 L), G.992.3 Annex M (ADSL2 M), G.992.5 (ADSL2+), G.992.5 Annex M (ADSL2+ M), G.994.1 (G.hs), G.996.1 (G.test), T1.413i2
•Ports: Power, DSL, Ethernet (1-4)
•Buttons: Reset, Wi-Fi Protected Setup
•LEDs: Power, Wireless, Ethernet (1-4), DSL, Internet, Ethernet WAN
•Cabling Type: CAT 5 UTP, RJ-11, RJ-45
•Antennas: 3
•Connector Type: Internal
•Detachable: No
•RF Pwr (EIRP) in dBm: 2.4GHz
802.11b: 17.5+/-1.5dBm Typical @ Normal Temp Range
802.11g: 17.5+/-1.5dBmTypical @ Normal Temp Range
Wireless-N 20MHz: 13.5+/-1.5dBm Typical @ Normal Temp Range
Wireless-N 40MHz: 13.5+/-1.5dBm Typical @ Normal Temp Range
5GHz
802.11a: 13.5+/-1.5dBmTypical @ Normal Temp Range
Wireless-N 20MHz: 8.5+/-1.5dBm Typical @ Normal Temp Range
Wireless-N 40MHz: 11+/-1.5dBmTypical @ Normal Temp Range
•Antenna Gain in dBi: 2.4GHz: RIFA 1 & RIFA 2 & RIFA 3 <= 4dBi (Typical)
5GHz: RIFA 1 & RIFA 2 & RIFA 3 <= 3.5dBi (Typical)
•UPnP able/cert: Able
•Security Features:

Password protected configuration for web access
PAP and CHAP authentication
SPI Firewall
Denial of Service (DoS) Prevention
URL filtering, and keyword, Java, ActiveX, Proxy, Cookie blocking
ToD filter (Blocks Access by Time)
VPN Passthrough for IPSec, PPTP, and L2TP Protocols
128, 64 bits WEP with Passphrase WEP key generation
WPA and WPA2 Personal and Enterprise
Trend Micro
SSID Broadcast Disable
Access restriction by MAC and IP addresses


Environmental Details
•Dimensions 202 x 34 x 160 mm
•Weight 362 g
•Power 12V 1.25A
•Certiication FCC, CE, IC-03, Wi-fi, A-Tick, Telepermit.
•Operating Temp. 0 to 40 C (32 to 104 F)
•Storage Temp. -20 C to 70 C (-4 to 158 F)
•Operating Humidity 10 to 85% Noncondensing
•Storage Humidity 5 to 90% Noncondensing
Minimum Requirements
•Internet Explorer 6.0, Safari 3.0, or Firefox 1.0 for web-based configuration
•PC with a Network Adapter and the TCP/IP Protocol installed
•CD-ROM drive
•Network Magic software and Setup Wizard require up-to-date Windows XP, Vista, or Vista 64-bit Edition
•Setup Wizard also runs under MAC OS X 10.4 or higher
•Activated ADSL line
