HARDWARE FEATURES
Interface PCI Express x1
Antenna Type Omni Directional, Detachable (RP-SMA)
Antenna Gain 3 x 2dBi
WIRELESS FEATURES
Wireless Standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE 802.11a
Frequency 2.4-2.4835GHz
5.180-5.240GHZ
5.745-5.825GHz

Signal Rate 11n: Up to 450Mbps(dynamic)
11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic)
11a: Up to 54Mbps(dynamic)
EIRP <20dBm(EIRP)
Reception Sensitivity 405M_2.4GHz: -68dBm@10% PER
270M_2.4GHz: -70dBm@10% PER
195M_2.4GHz: -71dBm@10% PER
130M_2.4GHz: -74dBm@10% PER
54M_2.4GHz: -79dBm@10% PER
11M_2.4GHz: -87dBm@8% PER
6M_2.4GHz: -94dBm@10% PER
1M_2.4GHz: -99dBm@8% PER
405M_5GHz: -64dBm@10% PER
270M_5GHz: -67dBm@10% PER
195M_5GHz: -70dBm@10% PER
130M_5GHz: -73dBm@10% PER
54M_5GHz: -79dBm@10% PER
6M_5GHz: -92dBm@10% PER
Wireless Modes Ad-Hoc / Infrastructure mode
Wireless Security Support 64/128 bit WEP, WPA-PSK/WPA2-PSK,802.1x
Modulation Technology DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM
OTHERS
Certification CE, FCC, RoHS,Wi-Fi
Package Contents Wireless Adapter
Resource CD
Quick Installation Guide
System Requirements Windows 7(32/64bits), Windows Vista(32/64bits), Windows XP(32/64bits)
Environment Operating Temperature: 0?~40? (32?~104?)
Storage Temperature: -40?~70? (-40?~158?)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
