Advanced Features

Live Parental Controls with flexible and customizable filter settings
Simultaneous Dual Band-2.4 GHz and 5 GHz operation
Two (2) ports for ReadySHARE? USB Storage Access-supports FAT16/32, NTFS Read/Write
DLNA?-stream media to DLNA media players
Multiple SSID guest networks (separate security and access restrictions)
Broadband usage meter measures Internet usage
Power and Wi-Fi on/off buttons

System Requirements

Broadband (cable, DSL) Internet service and modem with Ethernet connection
2.4 or 5.0 GHz 802.11a/b/g/n specification wireless adapter or an Ethernet adapter and cable for each computer
Microsoft? Windows? 7, Vista?, XP, 2000, Mac OS?, UNIX?, or Linux?
Microsoft? Internet Explorer? 5.0, Firefox? 2.0 or Safari 1.4 or higher
Use with an N600 Wireless Dual Band USB Adapter (WNDA3100 for maximum performance)


Standards

IEEE 802.11 b/g/n 2.4 GHz
IEEE 802.11 a/n 5.0 GHz
Five (5) 10/100/1000 (1 WAN and 4 LAN) Gigabit Ethernet ports
Two (2) USB 2.0 ports
One (1) ADSL2+ port


Performance

All-in-one-High Speed ADSL2+ Modem (built-in) and WAN Gigabit Ethernet port for cable/fiber
Powerful Dual Core (400 MHz each) processor
High speed access to external USB storage using 2 USB 2.0 ports
Memory: 128 MB Flash and 128 MB RAM
Five (5) (1 WAN, 4 LAN) Gigabit Ethernet ports
Advanced Quality of Service (QoS)


Security

Wi-Fi Protected Access? (WPA/WPA2-PSK) and WEP
Double firewall protection (SPI and NAT firewall)
Denial-of-service (DoS) attack prevention


Ease of Use

Easy installation-connect to PC and open your browser to install
Push 'N' Connect using Wi-Fi Protected Setup? (WPS)1


Physical Specifications

Dimensions: 223 x 153 x 31 mm (8.8 x 6.0 x 1.2 in)
Weight: 0.5 kg (1.2 lb)
