Dual-band Wireless-AC2400 Gigabit Router
Ultra-fast 802.11ac Wi-Fi router with a combined dual-band data rate of 2334 Mbps for smooth up to 4K/UHD video playback, ultra-fast file-sharing of large files and low-latency online gaming.
World's first 4x4 MU-MIMO antenna design with AiRadar universal beamforming for unrivaled multi-device performance and wireless signal coverage up to 465 m? (around 5,000ft?)1
Built-in USB 2.0 and USB 3.0 ports for up to 10-times faster data transfers to USB storage devices2, printer sharing, and 3G/4G dongle support.
ASUSWRT graphical user interface for easy, CD-free 30-second setup and hassle-free advanced network control.
AiProtection with Trend Micro with triple-strength total network security, plus robust parental controls and privacy protection.
ASUS AiCloud 2.0 lets you access, sync, share and stream your files anywhere, on any internet-connected device
Network Standard
IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IPv4, IPv6Product Segment
AC2400 ultimate AC performance: 600+1734 MbpsData Rate
802.11a : 6,9,12,18,24,36,48,54 Mbps
802.11b : 1, 2, 5.5, 11 Mbps
802.11g : 6,9,12,18,24,36,48,54 Mbps
802.11n : up to 450 Mbps
802.11n TurboQAM:up to600 Mbps
802.11ac: up to 1734 MbpsAntenna
External antenna x 4Operating Frequency
2.4GHz/5GHzEncryption
64-bit WEP, 128-bit WEP, WPA2-PSK, WPA-PSK, WPA-Enterprise , WPA2-Enterprise , WPS supportFirewall & Access Control
Firewall: SPI intrusion detection,DoS protection
Access control: Parental control, Network service filter, URL filter, Port filterManagement
UPnP, IGMP v1/v2/v3, DNS Proxy, DHCP, NTP Client, DDNS, Port Trigger, System Event LogVPN Support
IPSec Pass-Through
PPTP Pass-Through
L2TP Pass-Through
PPTP server
OpenVPN server
PPTP client
L2TP client
OpenVPN clientWAN Connection Type
Internet connection type : Automatic IP, Static IP, PPPoE(MPPE supported), PPTP, L2TP
Dual Link support
WAN Bridge support
Multicast Proxy support
Multicast Rate Setting supportUtilities
.Download master
- support BT, NZB, HTTP, ED2K
- support encryption, DHT, PEX and magnet link
- upload and download bandwidth control
- download scheduling
.Media server:
- Image: JPEG
- Audio: mp3, wma, wav, pcm, mp4, lpcm, ogg
- Video: asf, avi, divx, mpeg, mpg, ts, vob, wmv, mkv, mov
.QoS:
- WMM
- User definable rules for IP/MAC/Port. Upload and Download bandwidth management.
- ACK/SYN/FIN/RST/ICMP with Highest priority
.Guest Network
- 2.4GHz guest network x 3, 5GHz guest network x 3
.Printer Server: multifunctional printer support(Windows nly), LPR protocol support
.File server: Samba and FTP server with account management
.PPTP VPN server
.Network map
.Traffic monitorPorts
4 x RJ45 for 10/100/1000/Gigabits BaseT for LAN, 1 x RJ45 for 10/100/1000/Gigabits BaseT for WAN
USB 2.0 x 1
USB 3.0 x 1Button
WPS Button, Reset Button, Power Switch, Wireless on/off Button, LED on/off ButtonLED Indicator
PWR x 1
Wi-Fi x 2
LAN x 4
WAN x 1
WPS x 1Power Supply
AC Input : 110V~240V(50~60Hz)
DC Output : 19 V with max. 2.37 A currentOS Support
Windows? 8.1
Windows? 8
Windows? 7
Windows? Vista
Windows? 2000
Windows? ME
Windows? XP
Windows? Server 2003
Windows? Server 2008
Mac OS X 10.1
Mac OS X 10.4
Mac OS X 10.5
Mac OS X 10.6
Mac OS X 10.7
Mac OS X 10.8
Mac OS X
Linux Kernel (Support Ubuntu only)
LinuxDimensions
289.5 x 167.6 x 47.5 ~ cm (WxDxH)Weight
747 gPackage Content
1 x RT-AC87U Wireless-AC2400 Dual Band Gigabit Router
1 x RJ-45 cable
1 x Power adapter
1 x QSG
1 x Support CD(user manual and ultility)Router Special Features
3G/4G data sharing, AiCloud, Printer server, Download Master, AiDisK, Multiple SSIDs, Parental ControlOperation mode
Wireless router mode
Access point mode
Media bridge mode
