System Requirements



Audio with 3.5 mm or RCA output including

Computer running on any major operating system (Windows, Mac, Chromebooks)

Smartphones

Tablets

Televisions

MP3 players

Gaming Consoles: PlayStation3, Xbox 360

Warranty Information

1-Year Limited Hardware Warranty

Package Contents



Right satellite

Left satellite

Subwoofer

3.5 mm to 3.5 mm cable

User documentation



Dimensions



Satellite

Height

170 mm (6.69 in)

Width

100 mm (3.93 in )

Depth

85 mm (3.34 in)

Weight

525 g (1.16 lbs)

Subwoofer

Height

265 mm (10.43 in)

Width

255 mm (10.03 in)

Depth

195 mm (7.67 in)

Weight

4.0 kg (8.82 lbs)

Control pod

Height

55 mm (2.16 in)

Width

72 mm (2.83 in)

Depth

72 mm (2.83 in)

Weight

200 g (7 oz)

Power/Charging Cable

200 cm (6.6 ft.)

Right satellite to subwoofer

185 cm (6.1 ft.)

Left satellite to subwoofer

185 cm (6.1 ft.)

Control pod hard wired cable

185 cm (6.1 ft.)



Technical Specifications



Speaker Type

2.1

Power Type

AC

Power Rating (RMS)

60 watts

Satellite: 2 x 15 watts (into 8 ohms, @1 KHz, @10% THD)

Subwoofer: 30 watts (into 4 ohms, @100Hz, @10% THD)

Power Adapter

100 - 240V (50/60Hz)

Connections

Inputs: Stereo RCA, 3.5 mm auxiliary inputs

Headphone jack: 3.5 mm

Driver Size

Satellite: 66 mm (2.6 in) full range phase plug speaker drivers

Subwoofer: 133 mm (5.25 in) front-firing dome driver

Sound Pressure Level (SPL Max)

>97 dBA

Signal -to-Noise Ratio (SNR)

Satellites: 80 dB, A-weighted

Subwoofer: 80 dB, A-weighted

Frequency response

55 Hz - 20 kHz

Input Impedance

8Kohm

Audio Controls

Bass, Volume,ON/OFF on control pod

Sensitivity

Satellites: 450mV

Subwoofer: 200mV
